SPECIFICATIONS

Battery Included: Yes

Brand Name: NJTY

Choice: yes

DIY Supplies: Electrical

Display Type: Analog Only

High-concerned chemical: none

Model Number: t6015

Origin: Mainland China

Semi-finishedproduct: No

NJTY T6015 Pointer Insulation Resistance Meter Detecting AC/DC Voltage , Transistor, Battery Peformance, 2000MΩ USB Rechargeable Megohmmeter for Electrical Testing

The NJTY® T6015 Pointer Insulation Resistance Meter is a professional, handheld insulation resistance tester (megohmmeter) designed for electricians and technicians to verify the integrity of wiring and electrical insulation. It provides reliable performance for a wide range of electrical testing and maintenance applications. CLASSIC ANALOG INSULATION TESTER, Your Reliable Partner for Critical Measurements!

Specifications:

Model: T6015

Rated Test Voltage: 100V, 500V, 1000V

Low-Resistance Alarm:

• 100V: <2MΩ

• 500V: <1MΩ

• 1000V: <200KΩ

Transistor Withstand Voltage Measurement: 100V, 500V, 1000V

Output Short-Circuit Current: Maximum 0.75mA

Measurement Range: 0-2000MΩ

Measurement Accuracy: 1MΩ-2000MΩ ±10%

Voltage Measurement Range:

• DC Voltage: 500V

• AC Voltage: 500V (50Hz)

Insulation Test Output Voltage: Rated voltage 90%-120%

Discharge Resistor: 10MΩ

Voltage Measurement Error: ±5% (full scale)

Battery Testing: 3.3V undervoltage indication

Insulation: The movement circuit and the case distance: >50 meters

Size: 161 x 96 x 45 mm

Powered Battery: 1x 3.7V 18650 rechargeable lithium battery

DESIGNED FOR PORTABILITY:HANDS-FREE CONVENIENCE

Integrated Strap Holes for Aerial Work & Easy Transport（the strap is not included in the package Keep your tools secure and your focus sharp — whether you’re in the air or on the ground. Ready for safe and stable mounting during aerial work. Perfect for professionals working at height.

Your Go-Anywhere Companion
For electricians, technicians, engineers, and DIY enthusiasts — made to fit your life, on and off the job.

Engineered for Hands-Free Efficiency
Designed to free your hands and focus your mind—wherever work takes you. Engineered for Convenient, Hands-Free Use

Powerful Magnetic Mounting
Strong integrated magnets provide versatile, secure attachment to any metal surface.

Adjustable Kickstand
Tilt up to 80° for the perfect ergonomic viewing angle on any desk or workspace.

Magnetic + Stand Flexibility
Switch effortlessly between mounted stability and stand-up clarity.

CUT THROUGH THE DIGITAL FOG,SEE REAL INSULATION

In environments with heavly EMl and moisture, where one reliable force tells true story flicker, a equipment health.CLASSIC ANALOG INSULATION TESTER-BR HARSH CONDITIONS & EXPERT JUDGMENTANALOG VS DIGITAL:CHOOSING THE RIGHT TOOL

Analog (Pointer Type):

• Instantaneous response for real-time monitoring

• Clear trend visualization at a glance

• Robust and durable design for long-lasting use

Digital (LCD Display):

• High accuracy with precise numerical readouts

• Easy-to-read values in any lighting condition

• Additional smart functions for enhanced utility

INSTANTANEOUS RESPONSE,TRENDS OF GLANCE

Unike digital meters,the analog pointers's speed to the aptitude reveal instant changes,allowing detect momentary breakdowns and observe trends with zero delay.

HERITAGE & COMMITMENT

More than just the meter, it's accumulated wisdom,judgment, and umwavering  commitment to safety safetls generations engineers. We continuously to build solutions the certain to provide the most certainlivex intuitive in awptertn extreme answer in all conditions. Choosing classic is choovering reliability in a changing world.
